France’s Rafale Fighters: Au Courant In Time?
Related Stories: Contracts - Awards, Contracts - Intent, Europe - France, MBDA, Mergers & Acquisitions, Middle East - Other, New Systems Tech, Other Corporation, Radars, Rumours, Support & Maintenance, Thales
(click for cutaway view)
Possible engine support contract (Feb 22/10)
Will Dassault’s fighter become a fashionably late fighter platform that builds on its parent company’s past successes – or just “the late Rafale”? It all began as a 1985 break-away from the multinational consortium that went on to create EADS’ Eurofighter. The French needed a lighter aircraft that was suitable for carrier use, and were reportedly unwilling to cede design authority over the project. As is so often true of French defense procurement policy, the choice came down to one of paying additional costs for full independence and exact needs, or losing key industrial capabilities by partnering or buying abroad. France has generally opted for expensive but independent defense choices, and the Rafale was no exception.
Those costs, and associated delays triggered by the end of the Cold War and reduced funding, proved to be very costly indeed. Unlike previous French fighters, which relied on exports to lower their costs and keep production lines humming, the Rafale has yet to secure a single export contract – in part because versions fielded to date have impaired capabilities in key roles. The Rafale may, at last, be ready to be what its vendors say: a true omnirole aircraft, ready for prime time on the global export stage. The question is whether that will come in time. Rivals like EADS’ Eurofighter, Russia’s Su-27/30 family, and the American “teen series” of F-15/16/18 variants are all well established. Meanwhile, Saab’s versatile and cheaper JAS-39 Gripen remains a stubborn foe in key export competitions, and the multinational F-35 juggernaut is bearing down on it.
- Dassault’s Rafale: Variants
- Dassault’s Rafale: Program
- Contracts and Key Events, 2009-Present [updated]
- Additional Readings
(click to view full)
The Rafale is a 9.5 – 10.5 tonne aircraft powered by 2 SNECMA M88 jet engines, each generating up to 16,500 pounds thrust with afterburner. Canards are used to improve maneuverability, especially for snap-shots in short-range dogfights, and radar shaping lowers the aircraft’s profile relative to 4th generation competitors like the Mirage 2000 or F-16. Carrier capability was a prime motivator behind France’s decision to go it alone with the Rafale program, and variants exist for both land-based and carrier use.
Despite its size, the Rafale can carry an impressive set of ordnance beyond its 30mm DEFA 791 cannon: up to 9.5 tonnes of weapons and stores on 14 pylons (1-2 on center fuselage, 2 below engine intakes, 6 underwing and 2 wingtip pylons), 5 of which are “wet” pylons that can carry heavy stores or fuel tanks. Its RBE2 mechanically-scanned array radar can direct MBDA’s MICA missiles, and future integration of the long-range Meteor is also planned. A combination of Thales/SAGEM’s OST Infrared Scan and Track optronics, and MBDA’s MICA IR medium-range missiles, allows the Rafale to supplement its radar-guided ordnance with no-warning attacks on enemy aircraft from beyond visual range. At present, this capability is only duplicated by Sukhoi’s SU-27/30 family, and advanced MiG-29s.
(click to view full)
The aircraft comes in several broad types, and also comes in different capability tranches.
Carrier-capable Rafales are single-seat fighters, and are referred to as Rafale Ms. They will become the French Navy’s only fighters, replacing the F-8P Crusader fighter, Etendard IVP reconnaissance aircraft, and Super Etendard strike aircraft. They feature the usual set of carrier modifications, including lengthened and strengthened landing gear, strengthened airframe and arrester hook for landings, and carrier landing electronics. The front-center pylon is deleted on this version, in order to make room for that landing gear.
French Air Force Rafales come in 2 broad types: the preferred 2-seat Rafale B, and the single-seat Rafale C. They will eventually replace the SEPECAT Jaguar, Dassault’s Mirage F1, and most of the Mirage 2000 family in French service.
(click to view full)
Within those designations, Dassault’s Rafales also come in capability tranches that are common across all versions.
Initial Rafale F1s are limited to air superiority missions, and included only Rafale-Ms intended as urgent replacements for the 1950s/60s era F-8P Crusaders that served as the French carrier force’s air superiority fighters. Rafale F1s are capable fighters and represented a huge upgrade for the Marine Nationale, but even in air superiority mode they lack the wide weapons fit of 4+ generation counterparts like the JAS-39 Gripen or modern F-15 Strike Eagles, the optimized cockpit and defensive systems of EADS’ Eurofighter, or the price advantages of Sukhoi’s SU-30 family.
Most of the Rafales currently in service are built to the F2 standard, which adds the ability to carry and use precision ground attack weapons. This standard includes 2-seat air force Rafale-Bs, single-seat Rafale-Cs, and naval Rafale-Ms. Key additions include radar ground attack and terrain-following modes, carriage of laser-guided bombs and Storm Shadow/ Scalp cruise missiles, its OSF IRST sensor and MICA IR missile capability, Link 16 datalink, and a buddy tanker pod for Rafale Ms. The F2 standard does not include integration of independent laser targeting capability, however, which is why French Rafales over Afghanistan had to operate in conjunction with Super Etendard and Mirage 2000D fighters.
Since 2008, all Rafales have been delivered in the F3 standard, which adds the ability to carry French ASMP-A air-launched nuclear missiles, allowing the Rafale to replace the Mirage 2000N in that role. Other modifications include full integration with the Reco NG reconnaissance pod, implementation of all currently planned modes for the RBE2 radar, antiship attack with the Exocet or ANF, the Gerfaut helmet-mounted sight, and support for an improved tanker pack.
The batch ordered in 2009 will also have improved protection suites and Thales’ RBE2-AA AESA radar, replacing the mechanically-scanned RBE2 array on previous aircraft. Ful integration with Thales’ Damocles surveillance and targeting pod is expected to be complete by 2010, and efforts to include MBDA’s Meteor long-range air-air missiles are ongoing. Some sources refer to Rafales fielded with all of these modifications as Rafale F4s, but the type has not been formally defined yet.
Nuclear capability is irrelevant to exports, but the addition of an AESA radar and full independent precision strike capability will go a long way toward making the Rafale more competitive with challengers like American F-16/15/18s, Saab’s JAS-39NG Gripen, EADS’ Eurofighter Typhoon, and the oncoming F-35 program.
(click to view full)
Unfortunately for the Rafale project, 1985 proved a perilous time to begin an expensive decade-plus weapons project. The end of the Cold War led to a severe funding crunch. Development took a long time, and fielding was delayed for many years. That delay left Rafales with great potential as a 4+ generation fighter, but limited operational capabilities compared to even previous-generation aircraft.
The first operational Rafale-M aircraft was delivered in 2000, to the Marine Nationale, and the type entered full service in 2004. Plans call for delivery of up to 60 Rafale Ms.
The end of 2004 saw initial delivery of 2-seat Rafale B fighters to the French air force, and 2005 saw delivery of the first single-seat Rafale C. The aircraft entered service with the air force in 2006. All Rafale B/C fighters have been delivered as F2s or F3s. Current plans call for delivery of 234 Rafale B/C aircraft by the end of the program, but actual numbers may well be lower.
For previous French fighters, domestic production has been supplemented, and subsidized, by strong export sales. To date, that has not been the case for the Rafale. Questionable precision ground attack capabilities for Rafale F1-F2s, coupled with limited integration beyond French weapons, has hurt the aircraft badly on the export market. To date, it has lost export opportunities in Greece (Eurofighter, then F-16), Morocco, The Netherlands (F-35A or JAS-39NG), Norway (F-35A), Saudi Arabia (Eurofighter), Singapore (F-15SG), and South Korea (F-15K), and the UAE (F-16E/F).
(click to view full)
Despite Dassault’s rosy projections for the global fighter market, therefore, this difficulty in finding foreign orders has choked expected investments and started to feed back into platform modernization issues. By 2006, the French armed forces had ordered just 120 Rafales (82 Rafale A-C for the Armée de l’Air, 38 Rafale M for the Marine Nationale) of the planned 294. About 70 Rafales had been delivered by 2009, when a new French purchase raised the order book to 180; but 2009 also saw production cut from 14 to 11 aircraft per year.
Additional multi-year buys are possible. Nevertheless, absent export orders, a combination of deteriorating global finances, future demographic crunches in Europe, and the advent of unmanned UCAV projects like the nEUROn throw additional Rafale production orders into question.
Fully modernized Rafale versions may be about to reap their first export win in Brazil, and have remained in contention for India’s MMRCA competition, Switzerland’s F-5 Replacement project, and rumored offers to Libya, Kuwait, Qatar, and even the UAE.
(click to view full)
Feb 24/10: Defense News reports that the French defense ministry’s ministerial investment committee has approved a “power-by-the-hour” type arrangement with M88 engine maker Safran. Rolls Royce has trademarked the term, which refers to a contract that pays for hours flown, rather than time and maintenance costs. The M88 arrangement would reportedly include a guaranteed number of flying hours, plus the spares and support required to meet those benchmarks.
The report refers to a “contract” running from 2010-2014, with optional extensions and adjustments available from 2014-2020. At this point, however, it’s not 100% clear whether a formal contract exists, or the ministry has just given approval to negotiate a contract along specific lines.
Feb 2/10: Thales Group announces a 10-year, fixed price sub-contract with Dassault Aviation, to provide a range of extended services and maintenance support for avionics equipment on Rafale combat aircraft in service with the French armed forces. These services will include “obsolescence management,” which is always a hazard given the short production cycle of many electronic components, and involves guaranteed availability rates.
The avionics support agreement with Thales flows from SIMMAD contract noted in the Dec 12/08 entry, whose initial 5-year base period is followed by 5 further options of 1 year each.
Dec 31/09: Defense Aerospace reports that on this date, France’s DGA awarded Dassault Aviation a multi-billion euro, multi-year production contract to deliver 60 Rafale F3 combat aircraft (50 Armée de l’Air, 10 Navy) under “Commande Globale no. 4” (global order #4). Deliveries are expected to begin in 2015, at an average rate of 10.5 aircraft per year (q.v. Nov 12/09). A supplementary deal would cover the modernization of 10 Rafale-M F1 naval fighters to the current F3+ standard (q.v. Nov 30/09 entry).
Defense Aerospace says that the orders have been confirmed by a DGA spokesman, while Dassault declined to comment. Related contracts have also reportedly been awarded to Snecma for M-88 engines, and to MBDA for weapons, but values and particulars were not disclosed. France does not have the same disclosure requirements as countries like the USA, and news outlets have reported that invidious comparisons between the Rafale’s French price and export price helped sabotage a sale to Morocco in 2007.
To date, France remains the fighter’s only customer. Commande Global IV reportedly brings the total number of Rafales ordered by France to 180, out of a planned total of 286 (228 air force, 58 navy). An option to order 9 additional aircraft under this order could return the program plan to 295 aircraft.
Nov 30/09: Defense Aerospace reports that French defense minister Hervé Morin has committed EUR 300 million to modernize 10 French Navy Rafale-M (F1) fighters. This would bring the French Navy’s in-service Rafales to 26 F3 aircraft, plus any new-build aircraft delivered in the interim.
The retrofits were originally expected in 2012, but were moved up to 2010 as part of the French government’s economic stimulus program. Aircraft M2 – M10 will be moved from Landivisiau naval air station to the existing Rafale F3 production line, and retrofitted over a period of 12-18 months. When delivered, they will replace 11F Squadron’s modernized Super Etendard fighters, which are nearing the end of their fatigue life.
Nov 26/09: French Defense Minister Hervé Morin is quoted regarding the September 2009 crash of 2 Rafales. Both recorders have been recovered and sent to France’s Bureau of Accidents Enquiring and Analysis (BEAD) for investigation. Morin says the report is complete, adding that: “It’s evident… It’s very probable, very certain to be a human error.” China’s Xinhua.
Nov 15/09: At the Dubai 2009 air show, Thales representatives discuss the expected French contract for 60 more planes, and export opportunities. Flight International:
”[The inclusion of RBE2-AA AESA radars] is paving the way in terms of technology for the export process,” says [Thales aerospace senior vice-president Pierre-Eric Pommellet]. “Negotiations with the UAE on Rafale are ongoing,” he says. “I’m sure that this will be a very important topic at Dubai. This is the biggest project that we are involved in in this region.” Kuwait is also emerging as a strong prospect. “There have been some state-to-state talks, including on the Rafale. Kuwait could be a good customer for us, but it’s their decision on whether to progress,” he says.”
Nov 12/09: Defense minister Hervé Morin and France’s Comité ministériel des investissements de défense (CMI) approve a multi-year, 60-plane order of Rafale fighters for the French air force and navy, per France’s multi-year defense budgeting plans. These aircraft would be equipped with new RBE2-AA AESA (Active Electronically Scanned Array) radars and improved self-protection systems, in addition to the standard Rafale F3 fit-out.
Order estimates hover around EUR 6-7 billion, but exact costs, delivery date, and order composition will now be negotiated by France’s DGA procurement agency. The multi-year commitment is designed to provide both assurance to the supply chain, and confidence on the part of potential export customers. The DGA itself acknowledges that the presence or absence of those exports will affect overall schedules and delivery dates. Key firms involved will include Dassault Aviation, Thales, Safran, and MBDA, among about 100 firms in the overall supply chain. French DGA [in French] | Avio News | Flight International | StrategyPage.
Oct 23/09: As Kuwait and France sign an umbrella defense agreement to enhance bilateral cooperation, reports surface that Kuwait is investigating Dassault’s Rafale as a possible successor to its fleet of F/A-18C/D Hornets. UPI:
“Obviously,” said [Kuwaiti Defense Minister Sheik Jaber al-Hamad] after meeting with his French counterpart Hervé Morin, “we would be proud to have the Rafale in the heart of the armed forces in Kuwait.” Jaber, also deputy prime minister of the emirate, told reporters he was awaiting terms of the deal from Paris.”
Oct 19/09: Libya’s Rafale purchase could be in danger. Russia’s Interfax media agency reports that Libya plans to buy 12-15 Sukhoi Su-35 multirole fighters, another 4 Su-30s as an immediate interim order, and 6 Yakovlev Yak-130 trainer and light attack aircraft aircraft. Reports indicate that a contract could be signed with state arms export agency Rosoboronexport by the end of 2009, or early 2010.
The UPI report adds that Libya is also interested in the long-range, high-altitude S-300 air-defense system, the shorter-range Tor-M2E and BUK-M1 surface-to-air missile systems, combat helicopters, T-90 tanks, and at least one diesel-powered submarine.
Libya has also been in talks with France to buy its Rafale fighters since late 2007. Any signed Sukhoi deal is likely to end the Rafale’s near-term chances in Libya.
Sept 24/09: A pair of French Rafale-M fighters collide and crash in the Mediterranean, about 30 km off the French coast. The crash reduces the Rafale M fleet from 17 – 15 aircraft, and kills one of the pilots involved. Aviation Week | Defense News | Flight International: body located.
Sept 7/09: Brazilan Rafales? Brazil’s Ministerio Da Defesa announces that Dassault Aviation is now the F-X2 competition’s preferred bidder, and the country will order 36 Rafales subject to further negotiations. Subsequent events lead to partial backtracking from the government, as the competition is still not over, and the Brazilian Air Force hasn’t delivered its recommendations yet. The Rafale has definitely achieved front-runner status, however.
This sale would be France’s 1st export order for its Rafale fighter, after numerous attempts spanning more than a decade. French technology transfer across a broad range of projects was reportedly the critical factor in the deal, and Brazilian Foreign Minister Celso Amorim reportedly said that the decision to begin talks with Dassault “was not adopted in relation to the other two” competing companies. President Luiz Inacio Lula da Silva described the move as “definitively consolidating a strategic partnership we started in 2005” – one that would now produce helicopters (EC725), submarines (nuclear-powered and diesel-electric), transport aircraft (KC-390) and possibly fighters (Rafale). Read “Brazil Embarking Upon F-X2 Fighter Program” for more details, and full updates.
June 5/09: Rumors surface that the UAE, who chose to develop the F-16E/F Block 60 Desert Falcon instead of buying the Rafale, may be willing to replace its Mirage 2000v9 fleet with Rafale aircraft in a $10 billion deal.
If they do, however, they reportedly want some changes to the platform, including engine thrust growth from 16,500 pounds each to 20,000 pounds, an AESA radar, and integration with MBDA’s Meteor long-range missile. Funding from the UAE could help France finance Rafale upgrades, as their key requests are all already planned or in development. where negotiations become interesting is the quid pro quo. A follow-on article in UAE’s The National discusses past licensing-for-exports deals associated with funded modifications to their Mirage 2000 and F-16 platforms. Those deals made the UAE several hundred million dollars when the Mirage 2000v5 modification it helped finance were sold to other countries. UPI | UAE’s The National.
(click to view full)
Dec 19/08: Alcatel-Lucent SA sells its 20.78% stake in major defense electronics firm Thales SA to Dassault Aviation SA of St. Cloud, France. The sale price is reported to be EUR 38 per share, or about EUR 1.57 billion (about $2.25 billion). Dassault already owns 5.2% of Thales, but this purchase will make it Thales’ second largest shareholder after the French government’s 27.1%. Read “Dassault Takes a Major Stake in Thales.”
Dec 12/09: Dassault announces that France’s Structure integrée de maintien en condition opérationnelle des matériels aéronautiques du ministère de la Défense (SIMMAD) has signed a 10-year contract to maintain the 120 Rafale fighters France has ordered to date for its Air Force and Navy.
This contract follows the nascent global trend toward pay for performance in military maintenance. The 10-year “Rafale Care” global contract does use maintenance payments based on operational availability and flying hours, rather than materials and labor. The contract also includes a commitment to reduce those costs per hour over time, in a similar manner to many corporate outsourcing agreements. Unlike Britain’s fully comprehensive “future contracting for availability” model, however, “Rafale Care” covers the aircraft but not the engine (Snecma), radar (Thales), countermeasures or weapon systems.
Costs were not disclosed, but Defense News quotes a Dassault spokesman as saying that the larger twin-engine Rafale costs about 15% more per flight hour than the Mirage 2000 lightweight fighter. The French Armée de l’Air also refused to provide figures, saying that they were heavily dependent on key variables like flight and mission profiles. Dassault Aviation | Defense News.
