AH-64E Apache Block III: Evolving Battlefield Roles

The AH-64 Apache will remain the US Army’s primary armed helicopter for several more decades, thanks to the collapse of the RAH-66 Comanche program, and the retirement sans replacement of the US Army’s Armed Reconnaissance Helicopter (ARH). Apaches also serve with a number of American allies, some of whom have already expressed interest in upgrading or expanding their fleets.

The AH-64E Guardian Block III (AB3) is the helicopter’s next big step forward. It incorporates 26 key new-technology insertions that cover flight performance, maintenance costs, sensors & electronics, and even the ability to control UAVs as part of manned-unmanned teaming (MUT). In July 2006, Boeing and U.S. Army officials signed the initial development contract for Block III upgrades to the current and future Apache fleet, via a virtual signing ceremony. By November 2011, the 1st production helicopter had been delivered. So… how many helicopters will be modified under the AH-64 Block III program, what do these modifications include, how is the program structured, and what has been happening since that 2006 award? The short answer is: a lot, including export interest and sales.

Taiwan’s Force Modernization: The American Side

Despite China’s ominous military buildup across the strait, key weapons sales of P-3 maritime patrol aircraft, Patriot PAC-3 missiles, and diesel-electric submarines to Taiwan had been sabotaged by Taiwanese politics for years – in some cases, since 1997. The KMT party’s flip-flops and determined stalling tactics eventually created a crisis in US-Taiwan relations, which finally soured to the point that the USA refused a Taiwanese request for F-16C/D aircraft.

That seems to have brought things to a head. Most of the budget and political issues were eventually sorted out, and after a long delay, some major elements of Taiwan’s requested modernization program appear to be moving forward: P-3 maritime patrol aircraft, UH-60M helicopters, Patriot missile upgrades; and requests for AH-64D attack helicopters, E-2 Hawkeye AWACS planes, minehunting ships, and missiles for defense against aircraft, ships, and tanks. These are must-have capabilities when facing a Chinese government that has vowed to take the country by force, and which is building an extensive submarine fleet, a large array of ballistic missiles, an upgraded fighter fleet, and a number of amphibious-capable divisions. Chinese pressure continues to stall some of Taiwan’s most important upgrades, including diesel-electric submarines, and new American fighter jets. Meanwhile, other purchases from abroad continue.

Soldier Battle JTRS: The HMS Radio Set + SANR

The Pentagon’s JTRS (Joint Tactical Radio System) aimed to replace existing radios in the American military with a single set of software-define radios that could have new frequencies and modes (“waveforms”) added via upload, instead of requiring multiple radio types in ground vehicles, and using circuit board swaps in order to upgrade. Trying to solve that set of problems across the entire American military meant taking on a very a big problem. Maybe too big. JTRS has seen cost overruns and full program restructurings, along with cancellation of some parts of the program.

JTRS HMS (Handheld, Manpack & Small Form-Fit) radios, for use by the individual solder, have survived the tumult, and are now headed into production. They offer soldiers more than just improved communications, and have performed in exercises and on the front lines. Now, production is ramping up.

Australia’s Hazard(ous) Frigate Upgrades: Done at Last

The FFG-7 Oliver Hazard Perry Class frigates make for a fascinating defense procurement case study. To this day, the ships are widely touted as a successful example of cost containment and avoidance of requirements creep – both of which have been major weaknesses in US Navy acquisition. On the other hand, compromises made to meet short-term cost targets resulted in short service lives and decisions to retire, sell, or downgrade the ships instead of upgrading them.

Australia’s 6 ships of this class have served alongside the RAN’s more modern ANZAC Class frigates, which are undergoing upgrades of their own to help them handle the reality of modern anti-ship missiles. With the SEA 4000 Hobart Class air warfare frigates still just a gleam in an admiral’s eye, the government looked for a way to upgrade their FFG-7 “Adelaide Class” to keep them in service until 2020 or so. The SEA 1390 project wasn’t what you’d call a success… but Australia accepted their last frigate in 2010, and the 4 remaining ships will serve until 2020.

Bringing Home the BACN to Front-Line Forces

In late June 2009, the USAF awarded Northrop Grumman Defense Mission Systems Inc., of San Diego, CA an urgent requirement contract for its Battlefield Airborne Communications Node (BACN) System. Under current plans, Northrop Grumman will help the USAF deploy BACN in up to 4 “E-11” Bombardier BD-700 Global Express (see also BACN-modified photo) ultra-long-range business jets, and in up to 4 EQ-4B Global Hawk Block 20 UAVs, for sustained deployment through 2015.

BACN is an airborne communications relay that extends communications ranges, bridges between radio frequencies, and “translates” among incompatible communications systems. That may sound trivial, but on a tactical level, it definitely isn’t.

WCSP: Mid-Life Upgrade for Britain’s Warrior IFVs

Britain’s MCV-80/FV510 Warrior Infantry Fighting Vehicle was produced between 1984 and 1995. Built of all-welded aluminum construction and armed with the 30 mm Rarden cannon, it was designed to destroy enemy armored personnel carriers at ranges of up to 1,500m, while offering a fast, armored battlefield taxi for up to 7 infantry soldiers. These IFVs were pressurized to protect against Soviet chemical and biological weapons, and included a full range of night vision equipment. They served capably during Operation Desert Storm in 1991, were used to maintain the peace in Bosnia/Kosovo, and have found themselves in very high demand on the post 9/11 front lines.

Individual programs have improved some vehicles’ optics, radios, and add-on armor, but keeping the fleet in service until 2035 will require more extensive work. Hence the GBP 1 billion Warrior Capability Sustainment Programme (WCSP). In mid-November 2009, BAE Systems and Lockheed Martin UK submitted their bids, but the decision took almost 2 years. Fielding isn’t expected until 2018, but work proceeds.

Belgium Upgrading its F-16s

Belgium is embarking on minor but useful modernization of its remaining F-16 fleet, which is expected to serve until at least 2022, and could easily end up serving past 2030. Under Belgium’s 2000-2015 Modernization plan, the Belgian Defense Forces plan to keep just 60 F-16s in the fleet, creating a total of 48 operational aircraft (46 for NATO duties and 2 for domestic air defense).

The Wonders of Link 16 For Less: MIDS-LVTs

What one sees, all see. Jam-resistant Link-16 radios automatically exchange battlefield information – particularly locations of friendly and enemy aircraft, ships and ground forces – among themselves in a long-range, line-of-sight network. For example, air surveillance tracking data from an Airborne Warning and Control System (AWACS) aircraft can be instantly shared with fighter aircraft and air defense units. More than a dozen countries have installed Link 16 terminals on over 19 different land, sea, and air platforms, making it an interoperability success story.

While recent advancements may make AESA radars the future transmitters of choice, Link 16 is the current standard. The Multifunctional Information Distribution System-Low Volume Terminals (MIDS LVTs) were developed by a multinational consortium to provide Link 16 capability at a lower weight, volume, and cost than the Joint Tactical Information Distribution System (JTIDS). This free-to-view DID Spotlight article throws a spotlight on the program, explaining Link 16, and covering associated contracts around the world.

The Larks, Still Bravely Singing, Fly… Elbit’s Skylark UAVs

Elbit’s Skylark-I mini-UAV has become a popular choice for portable “over the hill” surveillance, as nations like Israel, Australia, Canada, France, Mexico, Poland, Sweden, et. al. adopt it for battlefield use. Bental’s electric propulsion system using brushless permanent magnetic motors is an especial benefit to Skylark operators, as its silent operation avoids warning enemy targets of its presence.

In an effort to build on that success, Elbit soon introduced the larger Skylark-II for battalion level UAV operations, fired from a rail launcher mounted on small wheeled vehicles rather than launched by hand. In exchange for the launcher requirement and a doubling of the crew size to 2, the Skylark-II gains a mission radius of 50-60 km instead of 10 km, and the ability to mount larger sensor packages. Awards soon followed from sources as varied as Popular Science and industry analysts Frost & Sullivan – but awards don’t pay the bills. Fortunately, orders have followed.

$1.1B to Upgrade Turkish F-16 fleet

The Turkish and US governments signed a letter of offer and acceptance (LOA) on April 26/05 for the $1.1-billion modernization of 117 Turkish Air Force F-16s to a common avionics configuration. December 2006 saw a $635.1 million contract under that framework issued to Lockeed Martin.

The upgrade will create a common avionics configuration for the service’s fleet of F-16 Block 40 and 50 aircraft. More than 200 F-16 aircraft make up the backbone of Turkey’s current fighter fleet. Systems to be integrated on Turkey’s upgraded F-16s include:
