Embraer’s Multinational KC-390 Tactical Air Transport Program

More supplier decisions. (Jan 19/12)

Global competition in the 20-ton air transport segment continues to intensify, with Brazil’s launch of its KC-390 program. Embraer figures reportedly place the global C-130 replacement market at around 700 aircraft. In response, it will develop a jet-powered rival to compete with Lockheed Martin’s C-130J, the larger Airbus A400M, Russia’s AN-12 and its Chinese copy the Yun-8/9, and the bi-national Irkut/HAL MRTA project. Smaller aircraft like the EADS-CASA C-295M, and Alenia’s C-27J, may also represent indirect competition.

Embraer is extending its efforts and markets by crafting a jet-powered medium transport with a cargo capacity of around 23 tons, that can be refueled in the air, and can provide refueling services to other aircraft by adding dedicated pods. The KC-390 has now become a multinational effort, and may be shaping up as the C-130’s most formidable future competitor…

• The KC-390: Program [updated]
• The KC-390: Aircraft
• Contracts and Key Events [updated]
• Additional Readings: Competitors

The KC-390: Program

Brazil’s aerospace industry has made impressive global gains in the civilian business and regional jet segments, and in the military market for primary trainer and counterinsurgency aircraft. Slumping civilian demand recently led to layoffs, but rising Brazilian defense budgets give the government a lever to inject funds into the company, while completing a strategic project that has been under consideration for a couple of years.

Overall, Embraer reportedly bases its business case on a break-even point of 120 orders, or about 1/7th of the tactical transport market outside of China, Russia, Ukraine and the USA.

The initial Brazilian contract covers R&D, and calls for 3 development aircraft, with a 28 plane production order to follow. This would allow the KC-390 to replace the Brazilian Air Force’s 21 C-130E/H and 2 KC-130H Hercules planes. That country also flies 10 aged DHC-5 Buffalo tactical transports that look like natural candidates for replacement; they are excellent aircraft, but their remaining lifespans are questionable.

To date, possible orders stand at 60, including Brazil’s 28, plus possible orders from Argentina (6), Chile (6), Colombia (12), the Czech Republic (2), and Portugal (6). South Africa’s cancellation of its A400M order may create another opportunity. Brazil’s F-X-2 fighter competition may lead to even more European orders: France has reportedly pledged to join the program and buy KC-390s if its Rafale fighter wins, and Sweden has promised to consider the KC-390 to replace its recently-upgraded C-130s with the KC-390 if the JAS-39BR wins.

Note, however, that none of these production orders is yet backed by a formal contract. Brazil has stated credible intent, and funded the development program, but the terms and conditions of other countries’ participation remain topics for negotiation, and no funds have been set aside yet. Until prospective orders turn into firm contracts, relying on any numerical commitments is premature.

Meanwhile, development continues on an aggressive schedule. The KC-390’s initial configuration is frozen, with the end of definition studies and wind tunnel testing. Other foreign risk sharing partners are expected to ramp up their own participation during the 12-month follow-on Joint Definition Phase, which is expected to begin in mid-2011 with the selection of initial industrial partners. The first prototypes are expected to fly in 2014.

The aircraft design itself will belong to the Brazilian government, with Embraer as the lead technical and industrial partner. All talks to join the program will be conducted at a government-to-government level, and the process of adding “risk sharing” partners will be a top-down process that results in directives handed down to Embraer.

Note that this kind of arrangement can create program risks, and obstacles to an aggressive schedule, if the partners selected by the Brazilian government fail to perform on an industrial level. Joint Definition Phase partnerships & commitments to date include:

• Aero Vodochody (Czech Republic) – Rear fuselage II section, Crew and parachutist doors, Emergency door and hatches, Cargo ramp, Fixed leading edge.

• BAE Systems (UK/USA) – Flight control computers, Actuator control electronics.

• Cobham plc (UK) – Aerial refueling pods.

• Denel Saab Aerostructures Ltd. (Sweden/ South Africa/ USA) – Composite components, in collaboration with HITCO. Reportedly includes an aft fuselage section, but their share is not confirmed.

• DRS Training & Control Systems – Cargo Handling and Aerial Delivery System.

• EEA (Portugal) – Engineering and testing work on 3 unspecified segments.

• Elbit Systems’ AEL (Israel/Brazil) – Mission computer, HUD, DIRCM, Self-protection suite.

• ELEB Equipamentos Ltda. (Brazil) – Landing gear. ELEB is an Embraer subsidiary.

• Esterline Control Systems (USA) – Autothrottle.

• Fabrica Argentina de Aviones (Argentina) – Wing spoilers, Doors for the nose landing gear, Ramp door, Flap fairings, Tail cone, and Electronic cabinet.

• Goodrich Corp. (multi) – Electro-hydrostatic actuators, actuator electronics, electrical controls.

• United Technologies’ Hamilton Sundstrand (USA) – Electric Power Generating System, Auxiliary Power Unit.

• International Aero Engines (multi) – V2500-5 engines. High thrust versions can reach 33,000 pounds. IAE is a joint venture between Pratt & Whitney, Rolls Royce, MTU and JAEC, with each partner focused on specific engine modules; the final assembly line is in Germany.

• Liebherr-Aerospace Toulouse SAS (France) – Cabin pressure and environmental controls.

• OGMA (Portugal) – Central fuselage panels, elevators, fairings and landing-gear doors. Embraer is a 45.5% shareholder.

• Rockwell Collins (USA) – Cockpit avionics: Pro Line Fusion.

• Safran Group’s Hispano-Suiza (France) – Emergency Electric Power Generator System.

• Safran Group’s Sagem-DS (France) – Horizontal Stabilizer Trim System, with electric actuators.

• SELEX Galileo (Italy) – T-20 Gabbiano Tactical Radar: performs basic land and sea surveillance, as well as navigation.

The KC-390: Aircraft

The C-390 was originally supposed to be a militarized ERJ-190 jet that competed in a unique niche between EADS-CASA’s C-295M and Lockheed Martin’s C-130 Hercules, and served Brazil’s postal service as its launch customer. The more the engineers worked, the more it diverged from that idea, until it assumed it present T-tailed, high-winged, hump-backed form as a full military aircraft and C-130 competitor.

In comparison to a stretched C-130J-30, the renamed KC-390’s cargo compartment is now 17.75m long (vs. 16.9m) and 3.45m wide (vs 3.12m); 2.9m high forward of the wing (vs 2.74m) and 3.2m aft of the wing. The KC-390’s wings were lengthened to 35.03m during the configuration phase, in order to allow helicopter refueling at speeds around 120 kt. With the right engines, the Force Aerea Braziliera (FAB) has confirmed that each aircraft will carry up to 80 troops, or a 20.9+ tonne/ 23+ ton total cargo load. That surpasses initial expectations of 19t, and places it close to competitors like Lockheed Martin’s C-130J at 21.8t.

The airplane will incorporate a modern, night-vision compatible avionics system, including 2 Head-Up Displays (HUD), and will use fly-by-wire technologies instead of all-mechanical control systems.

The most unusual feature in current mockups may be a movable pressure bulkhead that retracts into the roof and descends to seal the cargo cabin. While it shortens the cabin from 17.75m to to 12.78m when deployed, it could allow high altitude airdrops from the space behind, without depressurizing the entire cabin. In order to improve airdrop accuracy, the KC-390 will use Computed Air Release Point (CARP) technology integrated with the fly-by-wire system.

Key decisions will include the aircraft’s engines, whose thrust requirement has grown to the 27,000 -30,000 pound class. Embraer was reportedly looking at the GE/Safran CFM56-5B, or the International Aero Engines joint venture’s V2500, both of which power many Airbus narrowbody passenger jets. The V2500 won.

A complete self-protection system will also be fitted, and Elbit’s AEL has been announced as the key supplier. Other firms may also become involved in supplying warning elements and decoys, to integrate with AEL’s SPS controller and DIRCM.

Contracts and Key Events

Jan 19/12: Embraer adds the KC-390’s Auxiliary Power Unit (APU) to Hamilton Sundstrand’s responsibilities.

APUs are small gas turbine engines that provide electric power, instead of propulsion. They’re used most often on the ground, providing electricity, compressed air, and/or shaft power for main engine start, air conditioning, electric power and other aircraft systems. They can also provide backup electric power during in-flight operation. The KC-390’s APU is derived from a commercial unit, adapted to military specifications. Hamilton Sundstrand.

Jan 18/12: Embraer picks Safran Group subsidiary Sagem DS to supply the KC-390’s Horizontal Stabilizer Trim System. It uses electric actuators, instead of hydraulic systems. Development work will be carried out at Sagem’s R&D center in Massy, near Paris. Sagem DS.

Dec 14/11: Embraer picks United Technologies Corp. subsidiary Hamilton Sundstrand in Windsor Locks, CT to supply the KC-390’s Electric Power Generating System. The system will be based on the firm’s 90 kVA integrated drive generator, which is currently used in a variety of military and commercial applications. Hamilton Sundstrand.

Dec 14/11: Portugal takes another step. Embraer Defense and Security signs a partnership contract with OGMA Industria Aeronautica de Portugal and Empresa de Engenharia Aeronautica, for the KC-390 program. Reports indicate that EEA and the Centre for Excellence and Innovation in the Automotive Industry (CEIIA) will do engineering work for 3 unspecified segments of the jet. The segments designed and tested in Portugal will then be manufactured by OGMA, along with a central fuselage section.

The industrial contract follows Portugal’s Sept 10/10 Declaration of Intent to replace its 6 C-130H/C-130H-30 transports with 6 KC-390s. That purchase contract is the next step. Note that state-owned OGMA was privatized in 2003, and its ownership structure is now 45.5% Embraer, 19.5% EADS, and 35% government. Embraer | Macau Hub | Portugal Daily View | See also Flight International follow-up | Flight International on 2003’s A400M backout.

Nov 10/11: Diario da Republica announces that Embraer is expected to receive up to EUR 87 million from the National Strategic Benchmark Framework (QREN), or other public funding sources, in order to establish the necessary industrial infrastructure for KC-390 work. Macau Hub.

Oct 25/11: Elbit Systems wins an initial order worth $25 million. They’ll supply the KC-390’s pilot Head-Up Display, the Self-protection suite to coordinate warning systems and decoy/jammer defenses, and the DIRCM jammer for use against infrared guided missiles. All equipment will be provided through their Brazilian subsidiary, AEL, which also supplies the KC-390’s mission computer. Elbit Systems | Embraer.

Oct 19/11: Embraer and the Brazilian Air Force hold a workshop, to encourage more Brazilian companies to bid as suppliers of KC-390 parts, components, systems and services. The Nationalization Index of the aircraft, as calculated according to the criteria of the Brazilian Economic and Social Development Bank (BNDES), is currently estimated at 60%.

Embraer notes that the NI can’t realistically rise above 70%, since there is no Brazilian manufacturer for the engines. It’s also realistic to expect downward pressure on that Brazilian “nationalization” from foreign workshare, which will be required as part of export efforts. At the same time, the KC-390 is part of an industrial strategy for Brazil, whose government will want to see a wider group of Brazilian firms involved. Around 80 Brazilian companies participated in the workshop. Embraer.

Sept 29/11: Safran Group’s Hispano-Suiza gets the award to supply the KC-390’s Emergency Electric Power Generator System (EEPGS). The EEPGS deploys in dire emergency situations, and uses the guaranteed existence of airflow to create power and keep key on-board systems running. It includes a Ram Air Turbine (RAT), RAT electric generator and generator control unit, and a deployment/ restow mechanism.

Sept 8/11: Cobham is picked to put the ‘K’ in “KC-390,” and supply its wing-mounted Aerial Refuelling Pods. That’s followed by an order with an initial contract value over of US$60 million. Cobham is a leading global supplier of such systems, which equip Airbus’ A330 MRTT, as well as the new Boeing KC-46A. Embraer | Cobham plc [PDF]

Sept 8/11: Embraer Defense and Security picks Italy’s SELEX Galileo to supply their T-20 Gabbiano Tactical Radar.

The T-20’s solid state amplifier technology is designed for better Mean Time Between Failures, reduced energy consumption, and smaller size relative to previous generation technologies. What’s even more important to Brazil is the fact that it’s usually carried on UAVs and surveillance aircraft, and can perform basic land and sea surveillance, in addition to navigation functions. Embraer | SELEX Galileo [PDF] | Gabbiano Family product sheet [PDF].

Sept 8/11: Embraer picks Elbit’s Brazilian subsidiary AEL Sietemas to supply the KC-390’s mission computer. AEL has worked with Embraer to supply mission computers and full avionics systems for most Brazilian combat aircraft, and losing the KC-390’s avionics suite competition to Rockwell Collins was a disappointment. This award gets them back into the program. AEL [in Portuguese]

July 26/11: Embraer Defense and Security chooses BAE Systems to provide some flight control electronics hardware, embedded software, system design and integration support. BAE has a history of producing fly-by-wire systems, and the firm will supply flight control computers and actuator control electronics for the KC-390. The system will be developed in Rochester, United Kingdom; and Johnson City, New York, USA. Embraer.

July 26/11: Embraer chooses Goodrich Corp. to provide the electro-hydrostatic actuators (EHA), electro-backup hydrostatic actuators (EBHA), actuator electronics, and electrical controls for the KC-390’s primary flight control system. Goodrich will develop and deliver the system through the joint efforts of its businesses Actuation Systems and Engine Control & Electrical Power Systems, as well as the Goodrich Electronic Systems Center. Embraer.

July 25/11: Embraer chooses International Aero Engines AG’s V2500-5 engine for the KC-390. Engineering work on this military variant of their V2500 engine has already started at IAE’s shareholder companies, and 1st deliveries of powerplants for prototype aircraft are scheduled to begin in 2013, with flight tests to start in 2014. Production engines are anticipated for 2015, with entry into service projected for later that year. Deliveries are anticipated to last at least through 2030. Embraer | IAE.

June 22/11: Embraer confirms plans to launch a stretched C-390 for the civil cargo market, adding a section ahead of the wing for a cargo door, and a section behind for balance and space. If launched, it will compete with offerings like civil Hercules aircraft, cargo conversions of passenger narrowbody planes like the 737, a possible commercial version of Kawasaki’s similar C-2, et. al.

This is not an unexpected move, vid. the Feb 18/09 entry. On the other hand, crossovers in this area are less common than you’d think, because the key traits of military and civil cargo planes don’t quite line up. Civil operators want low-cost operation, and generally transport predictable palletized loads. Military operators want performance for operations like fast ingress/egress, short runways, and loads that place a lot of weight on smaller sections of the plane. That often leads to higher-cost tradeoffs like more powerful engines that consume more fuel, highly strengthened floors that add more weight, and airframes optimized for lift rather than super-efficient cruise. The steady progression of the KC-390 design away from a standard Embraer ERJ 190 airframe is a classic example of those tradeoffs at work.

Embraer officials are nonetheless predicting 200-250 C-390 orders, from the plane’s projected launch in 2018 to 2030 or so. If they can pull off anything like that, the military program will become even more competitive as costs and prices drop, and Embraer will do extremely well financially. They do have a slight advantage in that their original intended C-390 customer, Brazil’s postal service, is almost certain to be their launch customer. Beyond that, their target market is likely to be with operators serving sectors like resource industries, who can use them to haul medium loads into remote locations. By the mid-2020s, however, their most significant competitor may not be an airplane at all. See Flight International.

June 21/11: Embraer Defense and Security announces that Esterline Control Systems in Sylmar, CA, USA will supply the KC-390’s autothrottle system. Modern aircraft have a significant computer control element. The autothrottle system’s 2 throttles and integrated controls calculate and transmit thrust demands from aircrew controls or autopilot functions, to the Full Authority Digital Engine Control (FADEC) electronics running the engines. Embraer.

June 16/11: Embraer Defense and Security announces that Liebherr-Aerospace Toulouse SAS in Toulouse, France will provide the KC-390’s environmental and cabin pressure control systems. The firm has a long-standing civil lrelationship with Embraer in this area, and the KC-390’s system will feature an integrated control architecture along with the pneumatic and mechanical components. Embraer.

May 5/11: Embraer picks Rockwell Collins’ Pro Line Fusion avionics system for the KC-390 cockpit, which will feed into 5 high-resolution 15” LCD displays. It will include: – An Integrated Flight Information Systems (IFIS) with electronic charts and enhanced maps; – Advanced Flight Management Systems (FMS) with Wide Area Augmentation System that supports Localizer Performance with Vertical guidance approaches; (WAAS/LPV) and Required Navigation Performance (RNP) capabilities – Advanced graphical flight planning capability; and – An Information Management System (IMS) to manage databases and facilitate wireless interaction with ground systems.

Rockwell’s system already complies with the most recent CNS/ATM requirements for flight in international civilian airspace, and the Pro Line fusion cockpit will give KC-390s commonality with the systems on some of Embraer’s Legacy business jets. Because it’s a commercial system, it also sidesteps any American ITAR legal restrictions on future aircraft sales. The loser is IAI/EAE, whose proposal (vid. Jan 5/11 entry) failed to win. Embraer | Rockwell Collins | Flight International.

April 13/11: At the LAAD Defense and Security conference in Rio de Janeiro, Embraer Defense and Security signs contracts with the Czech Republic’s Aero Vodochody and Fabrica Argentina de Aviones to join the KC-390’s Joint Definition Phase, and produce parts for the program. Their acceptance is another step toward the commitments each government has made to buy the production aircraft.

Aero Vodochody will supply the rear fuselage II section, crew and parachutist doors, emergency door and hatches, cargo ramp and fixed leading edge for the prototypes, and for the future serial production aircraft. Embraer.

FAdeA will manufacture the spoilers (plates on the top surface of a wing for controlling wing lift), doors for the nose landing gear, ramp door, flap fairings, tail cone, and electronic cabinet. Embraer.

Embraer adds that “The program is running on schedule. Production of the first prototype is expected to start in 2013, followed by the first flight in 2014.”

April 6/11: Embraer publicly designates its subsidiary ELEB Equipamentos Ltda. of in São José dos Campo, Brazil to develop and produce the KC-390’s landing gear.

April 5/11: A Flight International report places the KC-390’s break-even point at 120 aircraft sold, about double the current commitments if all parties follow through.

That’s about 17.1% of the expected available tactical airlifter market, which Embraer reportedly places at of 700 or so replacement aircraft outside of China, Russia, and the USA. On its face, that seems a somewhat challenging but achievable total, given that other key buyers like India (MRTA with Russia) are also no-go markets. Contemplation of how many customers that entails at various purchase numbers, however, makes one wonder if their 700 aircraft figure has become too optimistic. A long future of austerity budgets due to the welfare state’s fiscal explosions may restrict remaining sales opportunities in “advanced” markets, to the point that even an expected uptick in rising regions like Asia and parts of Africa can’t compensate. Even a smaller overall market wouldn’t make Embraer’s success impossible, but it would change the relative ratio of required wins against powerful competitors.

March 22/11: Finmeccanica subsidiary DRS Training & Control Systems in Fort Walton Beach, FL gets an undisclosed contract from Embraer S.A. to design, develop, test, produce, and support the KC-390 Cargo Handling and Aerial Delivery System (CHS/ADS).

The KC-390 CHS/ADS is one of the 5 major aircraft subsystems, used for loading both palletized cargo and rolling stock onboard, and for rolling out cargo on paradrops. CHS/ADS includes an electrical pallet locking system, an electronic load master control subsystem with DO178 level A software certification, retractable guide-rails, invertible cargo rollers, tie-down devices, and other floor panel components. DRS Technologies.

Feb 25/11: Embraer has frozen the configuration of its KC-390 tanker/transport, and plans to begin the joint definition phase in May 2011, once final decisions are made on major sub-contractors. Aviation Week describes a full scale mockup at Embraer’s plant in Sao Jose do Campos.

Recent changes include longer wings (now 35.06 m), to enable slower 120 kt flight for helicopter refueling with the hose-and-drogue pods. Some customers are reportedly interested in a refueling boom as well, and Embraer is looking into this but doesn’t have a design it likes yet. The most unusual feature may be a movable pressure bulkhead that retracts into the roof and descends to seal the cargo cabin. While it shortens the cabin to 12.78m, it would allow high altitude airdrops from the space behind, without depressurizing the entire cabin.

Jan 5/11: Flight International reports that IAI and Synergy’s EAE joint venture is offering cockpit avionics and aircraft self-protection systems for the KC-390, under a 2009 cooperation pact.

IAI already has a presence in Brazil, supplying radars and maintenance services, and rumors of electronic intelligence or airborne early warning system KC-390 variants would play to IAI strengths. It’s worth remembering, however that both Embraer (ERJ-145 based R-99A) and IAI (Gulfstream G550 based CAEW) already have established AWACS offerings based on efficient, long endurance business jets. This makes the business case for an E-390 AWACS offering problematic for both parties.

Nov 23/10: Embraer begins the 1st phase of its new EUR 48 million, 330,000-square-foot (30,660-square-meter) facility in Evora, Portugal, dedicated to manufacturing complex airframe structures and components in composite materials. Construction is expected to be complete by the end of 2011, though production phase wouldn’t start until 2013. A 2nd phase will focus on metallic airframe structures.

Evora lies in the Alentejo region, 130 km east of Lisbon. Recently, the city developed an aerospace sector by creating a 9.4 million-square-foot (873,290-square-meter) aerospace industrial park, located near the municipal airfield. Embraer was the first investor. Ramos Catarino S.A. in Febres, Portugal is handling the excavation work, foundations and infrastructures. Construction was spurred by a wider strategy, but If Portugal goes ahead with a KC-390 buy, these facilities will already be in place for industrial offset work, and their construction costs may also count. Embraer.

Oct 29/10: Embraer announces that:

“As a result of the conversations held between the Brazilian and the Argentine Defense Ministries, the ministers Nelson Jobim and Nilda Garre signed, this week, a Declaration of Intent regarding the South American neighbor’s participation in the development program of the KC-390 military transport jet. The agreement marks the beginning of negotiations for the involvement of Fábrica Argentina de Aviões “Brig. San Martín” S.A. – FAdeA in the manufacture of the new airplane, as well as the future acquisition of six KC-390 aircraft by the Argentine government.”

FAdeA was Lockheed Martin Aircraft Argentina during its privatized period, but is now state-owned again. The firm has collaborated with Embraer on a twin-prop regional airliner (the canceled CBA 123) and refurbished C-130s, but it also has a long history of aircraft development. Its best-known product is probably the IA-58 Pucara counter-insurgency aircraft, and they are currently developing an IA-73 basic jet trainer to go with their IA-63 Pampa advanced jet trainer. Flight International.

Sept 21/10: Reports indicate that Brazil and the UAE are negotiating an an umbrella agreement for military cooperation, with sales of Super Tucano trainer/light attack turboprops and KC-390 transports as key building blocks. Brazilian defense minister Nelson Jobim told reporters that Brazil would present the UAE with a draft agreement within 2 weeks, and hopes the deal could be signed within 2 months of a mutual draft.

The UAE would be a very significant customer. It has modernized its transport capabilities with a major C-17 buy, but negotiations to complement its 6 C-17As with 12 C-130J-30 Super Hercules planes have been bogged down for 18 months. A switch to the KC-390, and participation in its development, would attract considerable notice in global military circles, and offer a bridge to further middle eastern sales. Abu Dhabi’s The National.

Sept 13/10: The Brazilian and Czech Ministries of Defence sign an agreement for Aero Vodochody a.s. will cooperate with Embraer to develop and build the KC-390. The firm has considerable experience in aerostructure manufacturing, and the Czech defense ministry believes they could end up manufacturing the KC-390’s rear fuselage, doors, and wing leading edges

Specific terms are expected to be signed by the end of 2010, and the Czech Republic is reportedly looking to buy up to 2 KC-390s as a complement to their C-295M fleet. Aero Vodochody | Aviation Week | Flight International.

Sept 10/10: Portuguese defense minister Augusto Santos Silva, signs a Declaration of Intent to join the KC-390 development program, and begin negotiations to finalize the terms and buy up to 6 planes.

The 6 KC-390s would replace the current fleet of 6 PoAF C-130H/C-130H-30 Hercules turboprops. Embraer | Reuters | In Portuguese: Portugal’s MDP | EFE | O Globo.

Sept 1/10: Colombian defense minister Rodrigo Rivera announces that the country is negotiating to join the KC-390 partnership, and have signed a Declaration of Intent. They are reportedly interested in buying up to 12 planes to replace their existing fleet of 7 C-130B/H Hercules aircraft, and possibly other models in the FAC’s inventory. In return, they would join as industrial partners, via Colombian Aeronautics Industry Corp. The FAC is familiar with Brazilian aircraft, flying EMB 312 Tucanos, EMB 314 Super Tucanos, and a pair of EMB 110 Banderiante twin-turboprop light paasenger/ transport planes.

The DoI was signed along with a broader set of agreements between Colombia and Brazil, covering economics, technology, environment and security. Marco Aurelio Garcia, a special adviser on Brazil’s international affairs, reportedly reaffirmed that the conflict with FARC’s narco-guerillas was solely Colombia’s internal issue, and Brazil would become involved only if Colombia requested it. That declaration is an obstacle to efforts by FARC and its backers in countries like Venezuela, who wish to pressure Colombia by internationalizing the conflict. Aviation Week | Defense News | defpro | Flight International | China’s Xinhua || In Spanish: La Republica | Terra Colombia | Vanguardia Liberal || DID: Colombia’s Defense Modernization.

Aug 24/10: Embraer publicly announces an signed Declaration of Intention from Chile to join the KC-390 program. That allows Chile’s Empresa Nacional de Aeronautica (ENAER) to join discussions about participating in its development, and acting as a supplier to the KC-390 and other programs. Embraer’s Phenom 100/300 and Legacy 450/500 business jets have been mentioned in that context. The DoI also begins negotiations with Chile’s FACh to buy up to 6 planes.

Chile has been discussing the purchase of 3 Airbus A400Ms for over 5 years now, but had not come to any agreement. It seems likely that any KC-390 purchase would supplant that buy. ENAER has been supplying structures for Embraer’s 50-seat ERJ 145 regional jet since the 1990s, and Chile’s FACh already flies 12 of Embraer’s EMB-314 Super Tucanos. Embraer | Defense News | Mercopress. In Spanish: Diario Financiero | EFE. In Portuguese: O Globo | ANSA Latina | DCI.

July 21/10: At the Farnborough 2010 show, Embraer and the Brazilian Air Force (FAB) announced the FAB’s intent to buy 28 KC-390s, and reveals additional details about the design.

The preliminary studies phase is done now, including wind tunnel tests, and aerodynamic, structural, and systems designs are all frozen. First flight is expected in 2014 and entry into service expected at the end of 2015. Embraer.

May 31/10: Brazil’s FAB offers an update, in the wake of their initial Workshop on KC-390 Offsets, held with 16 foreign firms at the Technology Park of Sao Jose dos Campos (SP), on May 25-26/10. Brazil’s Department of Aerospace Science and Technology (DCTA) organized and promoted the workshop.

Some of the KC-390’s equipment, from engines to instrumentation, will come from outside Brazil. Those firms will be required to offer industrial offsets to Brazilian firms, as the price of their participation in the project. Offsets could include production contracts for the KC-390 or other sales, or a range of activities from staff training, technology transfer, joint development of systems and supply of machine tools, etc.

The FAB adds that according to studies made by Embraer, there is a potential market of 700 aircraft in this class over the next 10 years. That may be so. Embraer will have to beat plenty of competitors, in order to secure its share of those orders. Brazil’s FAB [in Portuguese].

Oct 4/09: Brazil’s FAB confirms that revised bids are in from all 3 short-listed contenders, and Saab’s offer clearly has significant support from the Swedish government.

Gripen International’s revised bid offers a wide range of elements, including: Full involvement in the Gripen NG development program; Complete technology transfer and national autonomy through joint development; Independence in choice of weapons and systems integration; Production in Brazil of up to 80% Gripen NG airframes, via a full Gripen NG assembly line; and Full maintenance capability in Brazil for the Gripen NG’s F414 engine. That last offer would largely remove the threat of future American interference, and it would be interesting to see how Gripen International proposes to achieve it. Gripen International touts “significantly lower acquisition, support and operating costs” for its plane, and all this would be backed by a firm proposal for full long-term financing from the government’s Swedish Export Credit Corporation.

The additional offers are equally significant. Brazil will have the sales lead for Gripen NG in Latin America, with joint opportunities elsewhere. Saab would join the KC-390 program as a development and marketing partner, and Sweden will evaluate the KC-390 for its long term tactical air transport needs, as a future replacement for its recently-upgraded but aging C-130 Hercules aircraft. Saab also proposes to replace Sweden’s aged fleet of about 42 SK60/ Saab 105 jet trainers with Embraer’s Super Tucano, but it received a SKr 130 million ($18.8 million) deal in September 2009 to upgrade the planes’ cockpit systems, and current Swedish plans would see the SK60s continue in service until mid-2017. FAB release [in Portuguese] | Gripen International release.

Sept 5/09: Brazil’s Ministerio Da Defesa announces that Brazil has secured French cooperation to develop Embraer’s KC-390 medium transport. Other reports indicate that France is set to buy 10-12 of the aircraft when they’re introduced. This would give the Armee de l’Air a small fleet that would offset the risks of late A400M delivery, provide a second source of immediate relief for the ancient C-160 Transall fleet, and offer a lower-capacity option that could either be used as a transport supplement, or converted to specialty roles.

The KC-390 announcement is part of an incipient deal for France’s Rafale fighters, and French technology transfer across a broad range of projects was reportedly the critical factor in the deal. President Luiz Inacio Lula da Silva described the Rafale buy as “definitively consolidating a strategic partnership we started in 2005.” Brazil will now produce helicopters (EC725), submarines (nuclear-powered and diesel-electric), transport aircraft (KC-390) and possibly fighters (Rafale) in cooperation with France, under a broad strategic partnership in the defense arena. MDD announcement [Portuguese] | Agence France Presse | France24 | CS Monitor | Reuters.

June 15/09: Aviation Week reports that Brazil is in talks with other countries to make the KC-390 an international program. Embraer’s EVP for defense and government programs, Orlando Jose Ferreira Neto, expects that foreign partners could be added as early as the end of 2009. He adds that it will be a top-down government process, with accompanying directives handed down to Embraer.

The article adds that Embraer’s choice of its 27,000 pound thrust class engine will also be made in the next 24 months. Safran has reportedly said they will bid one of their GE partnership’s CFM engines. Pratt & Whitney and Rolls Royce are also obvious contenders.

May 1/09: South Africa’s Engineering News reports interest among South African industry, but the country is already committed to buying 8-14 of Airbus’ larger A400M transport. Some of the skills involved in that order would definitely transfer, but a South African KC-390 order would be fiscally difficult. Excerpt:

“In February, Denel Saab Aerostructures (DSA) CEO Lana Kinley told Engineering News Online that “we are very interested in having Embraer as a customer, and in being a risk-sharing partner on the C-390”. DSA sister company Denel Dynamics is already involved in a partnership with the FAB to develop the A-Darter air-to-air missile.”

April 14/09: At the 7th Latin America Aero and Defence (LAAD) trade fair in Rio de Janeiro, Embraer announces a contract from the Brazilian government to develop the KC-390. Figures are not disclosed, but the project’s scope is reported in other venues as around $1.4 – 1.5 billion over 7 years, with the aim of manufacturing 23 planes for Brazil, and inducting the first operational aircraft in 2015.

Embraer Defence VP Orlando Ferreira Neto tells Aviation Week that the program will help Embraer toward the goal of increasing its defense business to 20% of revenues, from 8% in 2008. As noted below, Colombia has expressed interest in a partnership. South Africa’s Engineering News reports that South Africa’s Denel Saab Aerostructures may also be interested in participating, but South Africa itself may face budget issues that would get in the way of a purchase. It is currently facing additional levies to keep its aging C-130 fleet flying, and has committed substantial funds to its participation in the larger A400M program. Aviation Week | Flight International | Engineering News | M & C Business.

Some reports say that Embraer’s upgrade of 12 Brazilian Navy A-4 Skyhawks [PDF], which fly from the carrier Sao Paolo (ex-Foch), is also part of this overall contract. Work on the Skyhawks will include restoration work, as well as new avionics, radar, electrical power, and autonomous oxygen generating systems; subcontracts to Elbit’s AEL are likely.

March 11/09: Brazil’s Ministerio da Defensa says that Colombia’s defense minister Juan Manoel Saints has expressed interest in becoming a partner in the KC-390 project, following their favorable experience with Embraer’s EMB-312 Tucano and EMB-314 Super Tucano trainers and light attack aircraft.

The comments come as the countries look to build bilaterial aerial surveillance along their common border, and Saints also makes a point of noting that the overall industrial and political relationship with Brazil is a strategic priority for Colombia. Spain’s El Economista | Defense-Aerospace translation.

Jan 26/09: SGL Group subsidiary HITCO Carbon Composites, Inc. in Gardena, CA announces a long-term strategic agreement with Denel Saab Aerostructures Ltd. to collaborate in composite components manufacturing for the Embraer C-390 Military Transport Aircraft.

Feb 18/09: Flight International reports that Embraer intends to secure civil certification for its proposed C-390 military airlifter, “in an attempt to sell the aircraft to civil freight operators such as FedEx Express and DHL.”

April 19/07: Flight International reports that Embraer has revealed planned details of its medium tactical transport, the C-390. This 19 tonne/ 21-ton capacity twin-jet airlifter will feature a high wing, rear ramp, fly-by-wire controls, and aerial refueling capabilities, and will compete in the replacement C-130 market.
